Series: AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.
Thickness: 0.016-1.5mm
Width: 1240mm
Warrantly ： Regular PE: 3-5 years ；
High Performance PE: 6-9 years；
PVDF: 15 years ；
FEVE: Two coats: between 10-15 years ；
FEVE: Three coats: 15-20 years
Application: aluminum composite panel, aluminum honeycomb, fireproof veneer, aluminum ceiling, shutters, roller shutter door, etc.
Product Description
Elevate your architectural and design projects with our premium 3D Black Color Aluminum Coil. This innovative product goes beyond standard finishes, featuring a deeply embossed, tactile texture that creates captivating light play and a sophisticated, multi-dimensional aesthetic. The rich, consistent black hue is enhanced by the shadowing effect of the 3D pattern, offering a bold statement for modern applications.
Engineered for performance, our coil combines this stunning visual appeal with the renowned durability of a PVDF or FEVE coating. It provides outstanding resistance to fading, scratching, and harsh weather, making it the ideal choice for creating iconic, long-lasting buildings and products.
Key Benefits & Features:
Captivating 3D Texture: A deep, consistent embossed pattern (e.g., linen, diamond, stucco) creates a dynamic visual effect and a premium tactile feel.
Ultra-Durable Black Finish: Advanced PVDF coatings ensure the deep black color maintains its intensity, offering superior resistance to UV fading, chalking, and chemical corrosion.
Excellent Formability: The high-quality aluminum substrate is designed to be formed and fabricated without compromising the integrity of the 3D texture or coating.
Lightweight & Versatile: Perfect for large-scale installations where weight is a concern, without sacrificing visual impact.
Low Maintenance: The non-porous, textured surface is resistant to dirt and fingerprints and is easily cleaned with water, reducing long-term upkeep costs.
Modern & Architectural: Provides a sophisticated alternative to flat finishes, adding depth and character to any design.
| Parameter / Feature | Specification Details | |
|---|---|---|
| Base Material | AA1100, AA3003, AA3004, AA5052 (or as required) | |
| Coating Type | PVDF (70%+ PVDF Resin), FEVE, or Durable PE | |
| Surface Finish | 3D Embossed Texture (e.g., Linen, Diamond, Orange Peel) | |
| Color | Deep Matte Black, Glossy Black, Anthracite Black | |
| Total Thickness | 0.5mm - 4.0mm (Customizable) | |
| Standard Width | 600mm - 1600mm (or as per customer requirement) | |
| Coating Thickness | Top Coat: 20 - 30 μm | Back Coat: 7 - 15 μm |
| Tensile Strength | 80 - 280 MPa (Varies by alloy) | |
| Peel Strength | Excellent adhesion, ≥ 100 N/cm | |
| Bending Performance | Excellent, texture remains intact after bending | |
| Salt Spray Test | ≥ 1000 hours (PVDF/FEVE) without red rust | |
| Warranty | Up to 20-25 years on color retention and coating integrity | |
| Certifications | ISO 9001, AAMA 2605, LEED Contributing, ROHS |
Common Applications:
Architectural Cladding: Building facades, curtain walls, and rainscreen systems.
Interior Design: Feature walls, ceiling panels, column covers, and decorative elements.
Signage & Branding: Luxury retail store fronts, corporate branding, and decorative logos.
Transportation: Interior paneling for yachts, trains, and high-end automotive trim.
Specialty Products: Elevator interiors, furniture, and appliance accents.
Why Choose Our 3D Black Aluminum Coil?
As a subsidiary of Jinhu Color Aluminum Group, we control the entire manufacturing process. This vertical integration allows us to guarantee:
Texture Consistency: Precise control over the embossing rollers ensures a uniform and deep pattern across every batch.
Color Uniformity: Our in-house coating expertise guarantees a rich, consistent black that perfectly complements the 3D texture.
Unmatched Quality: Rigorous quality checks at every stage ensure a product that is as durable as it is beautiful.
Custom Solutions: We offer custom textures, widths, thicknesses, and packaging to meet the most demanding project specifications.
Request Your Free Sample Today!
Experience the depth and quality of our 3D Black Aluminum Coil firsthand. Contact us to request a free sample and see how it can transform your next project.
