Flat Color Aluminum Coil

Series: AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.

Thickness: 0.016-1.5mm

Width: 1240mm

Warrantly ： Regular PE: 3-5 years ；

High Performance PE: 6-9 years；

PVDF: 15 years ；

FEVE: Two coats: between 10-15 years ；

FEVE: Three coats: 15-20 years

Application: aluminum composite panel, aluminum honeycomb, fireproof veneer, aluminum ceiling, shutters, roller shutter door, etc.

Send Inquiry Send Email

Product Description

Flat Color Aluminum Coil: Unmatched Consistency & Durability for Your Projects

Discover the industry-leading Flat Color Aluminum Coil, engineered for applications demanding a flawless, consistent matte or glossy finish and exceptional long-term performance. Our coils undergo a rigorous coating process, resulting in a uniform, vibrant color that resists chipping, fading, and weathering.

Ideal for architectural cladding, roofing, gutters, industrial applications, and appliance manufacturing, this coil provides the perfect blend of aesthetic appeal, formability, and structural integrity. As a subsidiary of Jinhu Color Aluminum Group, we leverage decades of expertise to deliver superior quality coils with competitive pricing and reliable supply.

Key Advantages:

Uniform & Vibrant Finish: Achieve a consistent, smooth matte or glossy appearance across large surface areas without color variation.
Exceptional Durability: Advanced PVDF (Kynar 500®/Hylar 5000®) or robust PE (Polyester) coatings provide superior resistance to UV radiation, chemicals, and harsh weather conditions.
Excellent Formability: The high-quality aluminum substrate allows for easy punching, cutting, bending, and deep drawing without damaging the coating.
Low Maintenance: The non-porous, resistant surface is easy to clean and requires no painting or sealing, reducing long-term costs.
Corrosion Resistance: A protective pretreatment and robust coating system prevent oxidation and corrosion, extending the product's lifespan.
Eco-Friendly & Recyclable: Aluminum is a sustainable material, and our coatings comply with international environmental standards (e.g., ROHS, REACH).

Technical Specifications Table

Parameter / Feature	Specification Details
Base Material	AA1000, AA3000, or AA5000 series aluminum alloys
Coating Type	PVDF (70% / 80% PVDF Resin) or PE (Polyester)
Surface Finish	Matte, Glossy, Metallic, Embossed
Standard Thickness	0.02mm - 2.0mm (Customizable)
Standard Width	600mm - 1600mm (or as per customer requirement)
Coating Thickness	Top Coat: 20 - 25 μm	Back Coat: 7 - 15 μm
ID / OD	150/250/405/500/505mm ID or customized
Peel Strength	Excellent adhesion, ≥ 100 N/cm
Bending Performance	T-Bend Test (1T-3T), no cracking
Salt Spray Test	≥ 1000 hours (PVDF), ≥ 600 hours (PE) without red rust
Warranty	Up to 20-25 years on color and gloss retention (PVDF)
Certifications	ISO 9001, ASTM, AAMA 2605 (PVDF), ROHS, SGS

Common Applications:

Architectural: Building facades & curtain walls, composite panels, roofing & gutter systems, sunshades.
Industrial: Appliance housings (refrigerators, AC units), electrical enclosures, signage, lighting.
Transportation: Truck trailers, interior paneling.
Consumer Goods: Furniture, DIY projects, decorative trim.

Why Choose Our Flat Color Aluminum Coils?

Our vertical integration as part of the Jinhu Color Aluminum Group means we have complete control over the production process—from molten aluminum to the final coated coil. This allows us to ensure:

Superior Quality Control: Rigorous checks at every stage guarantee a flawless product.
Cost-Effectiveness: Eliminating middlemen reduces costs, offering you better value.
Customization: We offer custom colors, thicknesses, widths, and packaging to meet your exact project specifications.
Expert Support: Our technical team provides expert guidance to help you select the perfect product for your needs.

Request a Free Sample & Competitive Quotation Today!

See the quality and match the color for your project. Contact us now to request free samples and get a detailed quote tailored to your requirements.
