Series: AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.
Thickness: 0.016-1.5mm
Width: ＜1600mm
Warrantly ： Regular PE: 3-5 years ；
High Performance PE: 6-9 years；
PVDF: 15 years ；
FEVE: Two coats: between 10-15 years ；
FEVE: Three coats: 15-20 years
Application: aluminum composite panel, aluminum honeycomb, fireproof veneer, aluminum ceiling, shutters, roller shutter door, etc.
Product Description
Superior PVDF or PE Coating: Our coils are finished with high-quality coatings (PVDF recommended for extreme environments) ensuring exceptional color retention, gloss control, and resistance to chalking, ensuring your project looks brilliant for decades.
Excellent Formability: Designed to be fabricated easily without compromising the integrity of the beautiful Apple Green finish. Perfect for bending, roll-forming, and cutting to precise specifications.
Unmatched Corrosion Resistance: The aluminum core provides a natural protective layer, enhanced by our pre-treatment and coating process, making it ideal for harsh coastal or industrial environments.
Eco-Friendly & Sustainable: Aluminum is 100% recyclable without loss of quality. Our Apple Green coils are a responsible choice for green building projects (like LEED certification) and environmentally conscious manufacturers.
Consistent Color & Finish: Achieved through a state-of-the-art continuous coating line, we guarantee batch-to-batch color consistency for large-scale projects, eliminating the risk of mismatched panels.
Below are our standard specifications for Apple Green Aluminum Coil. Do you need a custom specification? [Contact us] for any special requirements regarding alloy, temper, or coating.
| Specification Category | Details |
|---|---|
| Material | Aluminum Alloy Series 1000, 3000, 5000 (e.g., 1100, 3003, 5005) |
| Temper | O (Annealed), H14, H16, H18, H24, H26, H32 etc. |
| Thickness | 0.2mm - 3.0mm (0.008" - 0.120") |
| Width | 100mm - 1600mm (4" - 63") |
| Inner Diameter (ID) | 150mm (6"), 405mm (16"), 505mm (20") or custom |
| Outer Diameter (OD) | Max 1800mm (71") |
| Coating Type | PVDF (70% or 80%), Polyester (PE), or FEVE |
| Coating Thickness | Top Coat: 20-25 μm, Total Paint: 30-35 μm (Customizable) |
| Surface Finish | Standard, Matte, Embossed |
| Standard | ASTM B209, EN 485, GB/T 3880, or customized |
Note: The above table represents common standards. All parameters can be customized to your project needs.
Our coil is versatile and built for a multitude of industries:
Architectural Cladding & Roofing: For stunning curtain walls, composite panels, and standing seam roofs.
Building Interiors: Elevator cabins, wall partitions, and decorative ceilings.
Automotive & Transportation: Trim, bumpers, and interior components for buses, trailers, and RVs.
Consumer Appliances: HVAC systems, home appliances, and electrical housings.
General Manufacturing: Furniture, signage, and DIY projects.
We are not just suppliers; we are your partners in creation. Every order is backed by our technical expertise and commitment to quality.
Ready to get started? Provide us with your specifications, and our team will provide a competitive quote tailored to your needs. We offer global shipping and just-in-time delivery to keep your production line moving.
Contact our sales team now for a personalized consultation and a free, no-obligation quote.
Get Your Free Quote in 24 Hours
FAQ Section
Q: Can I get a sample of the Apple Green Aluminum Coil?
A: Absolutely! We provide physical color chips and small sample coils to help you verify the color and quality before placing a bulk order.
Q: What is the lead time for production?
A: Standard products typically ship within 10-15 working days. Lead times for custom orders will be confirmed based on the specifics.
Q: Do you offer other colors?
A: Yes! We have a vast RAL color chart and can match almost any color you require. Ask us about our custom color matching service.
Q: What certifications do your products have?
A: Our products and processes are certified to meet international standards, including ISO 9001, ASTM, and EN standards. Specific certifications are available upon request.
