Product Description
Elevate your projects with our high-performance Painted Aluminum Coil, the versatile and durable solution for countless applications. We transform raw aluminum into a precisely coated, ready-to-fabricate material that combines stunning aesthetics with exceptional resilience against the elements.
Whether you're an architect designing a landmark building, an engineer manufacturing durable goods, or a fabricator seeking reliable materials, our coils offer the perfect blend of form and function. Available in a limitless spectrum of colors and finishes, they are your canvas for innovation.
[(Button: Request Your Free Quote & Color Chart!)]
Superior Durability: Our coatings, especially PVDF (Kynar®500), provide outstanding resistance to UV radiation, ensuring minimal color fading and chalking for over 20 years, even in harsh environments.
Exceptional Corrosion Resistance: A robust chemical pretreatment process prepares the aluminum surface, creating a bond that resists blistering, peeling, and corrosion from moisture, salt spray, and industrial pollution.
Cost-Effective Manufacturing: Receive material ready for immediate fabrication. Eliminate the cost, time, and environmental challenges of post-painting, streamlining your production line.
Eco-Friendly Solution: Our coating process is compliant with stringent environmental regulations (e.g., low VOC). Aluminum is also 100% recyclable at the end of its long life.
Design Flexibility: Choose from any RAL color, custom matches, metallic finishes, gloss levels (from matte to high-gloss), and even wood grain or stone patterns.
Our painted aluminum coils are manufactured to meet global quality standards. The table below details our standard offerings. We specialize in custom orders to your exact specifications.
| Specification Category | Standard Options & Capabilities | |
|---|---|---|
| Base Alloy | 1000 Series (1050, 1060, 1100), 3000 Series (3003, 3004, 3005), 5000 Series (5005, 5052, 5754) | |
| Temper | O (Annealed), H12, H14, H16, H18, H22, H24, H32, H34 | |
| Thickness | 0.1 mm - 3.0 mm (0.004" - 0.118") | |
| Width | 100 mm - 2000 mm (4" - 79") | |
| Inner Diameter (I.D.) | 150 mm (6"), 405 mm (16"), 500/505 mm (20"), 610 mm (24") | |
| Coating Type | PVDF (Polyvinylidene Fluoride): Premium weatherability. PE (Polyester): Excellent balance of cost and performance. FEVE: Superior gloss and color retention. ACP Finish: For aluminum composite panel production. | |
| Coating Thickness | Top Coat: 20-25 μm | Total Paint System: 25-35 μm (Fully customizable) |
| Surface Finish | Glossy (e.g., 80%), Matte, Mirror, Embossed (e.g., hairline, stucco), brushed | |
| Film Application | Optional PE protective film (one or two sides) to prevent surface damage during transport and fabrication. | |
| Standards | ASTM B209, EN 485, AAMA 2603, AAMA 2604, AAMA 2605, QUALICOAT, GSB |
The versatility of pre-painted aluminum makes it the material of choice for a wide range of industries:
Architectural & Construction: Building facades (ACM panels), curtain walls, roofing & siding, gutters & downspouts, ceiling systems, and architectural accents.
Transportation: Automotive trim, truck trailers, RV panels, marine applications, and interior van linings.
Consumer & Industrial Appliances: Refrigerator and freezer cabinets, air conditioner housings, washing machine drums, and electrical enclosures.
General Manufacturing: Signage, nameplates, lighting fixtures, furniture, partitions, and DIY projects.
We are committed to more than just delivering a product. We deliver solutions.
Global Reach: We reliably serve clients across North America, Europe, the Middle East, and Asia with compliant, high-quality materials.
Technical Expertise: Our team can advise on the best alloy, temper, and coating system for your specific application and environmental conditions.
Quality Assurance: From raw material to finished coil, our process is controlled by stringent quality checks to ensure every meter meets your expectations.
Bulk & Custom Orders: We are equipped to handle large-volume orders with consistent quality and competitive pricing.
Ready to get started? Contact our sales team with your requirements. We provide free sample cards and material samples for your evaluation.
Frequently Asked Questions (FAQ)
Q: What is the difference between PVDF and PE coating?
A: PVDF coating offers superior resistance to UV fading and chalk resistance, making it ideal for exterior architectural applications. PE coating provides excellent durability and color retention at a more economical price point, suitable for many industrial and interior uses.
Q: Can you match a specific color?
A: Absolutely. We have advanced color matching technology and can replicate any color sample or RAL number you provide.
Q: What is the lead time for production?
A: For standard colors and specifications, lead time is typically 10-15 working days. Custom orders may require 3-4 weeks. We always confirm lead times before order confirmation.
Q: Do you offer mill test certificates?
A: Yes, we provide full Mill Test Certificates (MTCs) and material certifications with every shipment, guaranteeing the chemical and mechanical properties of the material.
